Name: Carbon Shipbuilding Steel Plate
SKU: 0

HOME > PRODUCTS > Carbon Steel > Carbon Steel Plate > Carbon Shipbuilding Steel Plate

Carbon Shipbuilding Steel Plate

Shipbuilding steel plate refers to the carbon and alloy steel plate used in offshore and marine contructions, common grades are A, B, D, E, AH32/36/40, DH32/36/40, and EH32/36/40 which ranged from different strength.

WhatsApp：+86 15275315165

Email：Irene@shouyuansteel.com

Product Description

Carbon Shipbuilding Steel Plate Description

Shipbuilding steel plate refers to hot-rolled steel for the manufacture of ship structures produced in accordance with the requirements of the construction society. Often used as a special steel ordering, scheduling, sales, a ship including ship plates, steel and so on.

The Shipbuilding steel plate can be divided into general strength structural steel and high strength structural steel according to its minimum yield point strength level.

AGICO supplies and exports 2 types of ship steel, medium strength shipbuilding plate and high strength shipbuilding plate. All steel plate product can be manufactured according to Society LR, ABS, NK, GL, DNV, BV, KR, RINA, CCS, etc.

Product Parameters

Product Name	Carbon Shipbuilding Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

Grade	C % ≤	Mn %	Si %	P % ≤	S % ≤	Al %	NB %	V %
A	0.22	≥ 2.5 C	0.10-0.35	0.04	0.40	-	-	-
B	0.21	0.60-1.00	0.10-0.35	0.04	0.40	-	-	-
D	0.21	0.60-1.00	0.10-0.35	0.04	0.04	≥ 0.015	-	-
E	0.18	0.70-1.20	0.10-0.35	0.04	0.04	≥ 0.015	-	-
A32 D32 E32	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	-	-
A36 D36 E36	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	0.015-0.050	0.030-0.10

Mechanical Properties

Grade	Thickness (mm)	Yieldpoint (Mpa) ≥	Tensile Strength (Mpa)	Elongation (%) ≥	V-impact Test			Cold Bend Test
					Temperature (℃)	Average AKV A kv /J		b=2a 180°	b=5a 120°
						Lengthways	Crosswise
						≥
A	≤ 50	235	400-490	22	—	—	—	d=2a	—
B					0	27	20	—	d=3a
D					-10
E					-40
A32	≤ 50	315	440-590	22	0	31	22	—	d=3a
D32					-20
E32					-40
A36	≤ 50	355	490-620	21	0	34	24	—	d=3a
D36					-20
E36					-40

Product Application

Packaging and shipping

Factory Display

FAQ

1. What products do you supply?
We supply carbon steel, galvanized steel, pre-painted steel, stainless steel, copper, aluminum, and structural steel sections. Our product range includes sheets, coils, pipes, bars, strips, angles, channels, I-beams, and H-beams.

2. Can you provide customized specifications?
Yes. We can supply products in different materials, grades, thicknesses, widths, lengths, and surface finishes. Please send us your detailed specifications so we can confirm availability.

3. What processing services do you offer?
Depending on the product and project requirements, we can provide cutting, slitting, custom sizing, and other processing services. Please provide your drawings, dimensions, tolerances, and processing requirements with your inquiry.

4. How do you ensure product quality?
Products are supplied according to the material, dimensions, specifications, and quality requirements confirmed in the order. Please inform us before ordering if your project requires specific inspections, tests, or documents.
