Name: A53 Seamless & Welded Carbon Steel Pipe
SKU: 0

HOME > PRODUCTS > Carbon Steel > Carbon Steel Pipe > A53 Seamless & Welded Carbon Steel Pipe

A53 Seamless & Welded Carbon Steel Pipe

A53 American standard seamless steel pipe is made of high-quality steel billets through hot rolling, cold drawing and other processes. The chemical composition and mechanical properties of this steel pipe comply with the requirements of American standard ASTM A53/A53M.

WhatsApp：+86 15275315165

Email：Irene@shouyuansteel.com

Product Description

A53 Seamless & Welded Carbon Steel Pipe Description

ASTM A53 seamless steel pipe has high strength, good toughness, good processing performance and welding performance. A53 American standard seamless steel pipes are available in a wide range of specifications, with a wide range of outer diameters and wall thicknesses. Because ASTM A53 seamless carbon steel pipe has excellent material properties and good processing performance, it is widely used in petroleum, chemical industry, electric power, machinery manufacturing and other fields. For example, in the petrochemical industry, ASTM A53 steel pipes can be used to transport high-temperature and high-pressure oil, natural gas and other media.

Product Parameters

Product Name	A53 Seamless & Welded Carbon Steel Pipe
Standard	EN/DIN/JIS/ASTM/BS/ASME/AISI etc.
Outer Diameter	Seamless: 1/4"-36"	Welding: 21.3mm-3620mm
	Round Tube: 1/2"-10"	Square Tube/Rectangular Tube: 15x15mm-400x600mm
Wall Thickness	Seamless: 1.25mm-50mm	Welding: 1.65mm-65mm
Length	3-12 meters, Support customization
Surface Process	Bright, Polished, Black
Other Services	Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.

Chemical Composition

A53	Grade	C	Mn	P	S	Cu	Ni	Cr	Mo	V
Type S (Seamless)	A	0.25	0.95	0.05	0.05	0.4	0.4	0.4	0.15	0.08
Type S (Seamless)	B	0.3	1.2	0.05	0.05	0.4	0.4	0.4	0.15	0.08
Type E (Resistance Welding)	A	0.25	0.95	0.05	0.05	0.4	0.4	0.4	0.15	0.08
Type E (Resistance Welding)	B	0.3	1.2	0.05	0.05	0.4	0.4	0.4	0.15	0.08
Type F (Furnace Welding)	A	0.3	1.2	0.05	0.05	0.4	0.4	0.4	0.15	0.08

Mechanical Properties

A53	Grade A	Grade B
Tensile Strength Min. psi (MPa)	48,000 (330)	60,000 (415)
Yield Strength Min. psi (MPa)	30,000 (205)	35,000 (240)

Physical Performance

Density 20°C Kg/dm³	Modulus of Elasticity Kn/² mm				Coefficient of Thermal Conductivity 20°C W/m K	Heat Capacity 20°C J/kg K	Resistivity 20°C Ωmm²/m
Density 20°C Kg/dm³	20 C°	300 C°	400 C°	450 C°	Coefficient of Thermal Conductivity 20°C W/m K	Heat Capacity 20°C J/kg K	Resistivity 20°C Ωmm²/m
7.85	210	192	184	179	51	461	0.20

Scope of Application

Construction: underground pipeline, underground water, hot water transmission, mechanical processing, bearing sleeve, processing machinery parts, etc.
Electrical: natural gas transmission, hydroelectric fluid pipelines, anti-static pipes for wind farms, etc.

Product Application

Packaging and shipping

Factory Display

FAQ

1. What products do you supply?
We supply carbon steel, galvanized steel, pre-painted steel, stainless steel, copper, aluminum, and structural steel sections. Our product range includes sheets, coils, pipes, bars, strips, angles, channels, I-beams, and H-beams.

2. Can you provide customized specifications?
Yes. We can supply products in different materials, grades, thicknesses, widths, lengths, and surface finishes. Please send us your detailed specifications so we can confirm availability.

3. What processing services do you offer?
Depending on the product and project requirements, we can provide cutting, slitting, custom sizing, and other processing services. Please provide your drawings, dimensions, tolerances, and processing requirements with your inquiry.

4. How do you ensure product quality?
Products are supplied according to the material, dimensions, specifications, and quality requirements confirmed in the order. Please inform us before ordering if your project requires specific inspections, tests, or documents.
